TOPCON CL-100 Computerized Lensmeter

TOPCON CL-100

Computerized Lensmeter

The Topcon CL-100 Computerized Lensmeter is a precision optical instrument designed for measuring the power and cylindrical axis of spectacle lenses, including single vision, bifocal, progressive, and contact lenses.

Specifications:

Lens Types: Measures single vision, bifocal, trifocal, progressive power lenses (PLL), and hard/soft contact lenses.

Measurement Modes: Sphere, cylinder, and axis readings.Prism measurements.Vertex distance adjustments.

Measurement Range:

Spherical Power: -25.00 D to +25.00 D.Cylindrical Power: 0 to ±10.00 D.Axis: 0° to 180°.Prism: Up to 10Δ (diopters).

Accuracy:

Sphere and Cylinder: 0.01 D resolution.Axis: 1° resolution.

Progressive Lens Measurement: Automatically detects progressive lenses and shifts to an hourglass display for alignment with a (+) target, simplifying the neutralization process.

Contact Lens Measurement: Supports measurement of hard and soft contact lenses using standard lens support and ring accessories.

Optical System Light Source: Built-in light source for illuminating the lens table, ensuring accurate readings.

Marking System: Unique cartridge-based marking device with ink cartridges for clear marking, even on coated lenses.

Dual Sensor System: Enhances measurement accuracy for various lens types.

Display and Interface Display: High-contrast digital LCD display for real-time measurement results.

User Interface: Icon-based interface for intuitive operation, suitable for both experienced and novice users.

Graphic Display: Unique graphic representation for progressive lens measurements, guiding the operator through the process.

Data Record Indicator: Displays measurement data clearly with menu selection for adjustment/mode settings.

Connectivity and Integration

Data Transfer: Supports data transfer via cable to Topcon’s CV system or 8000 SUPRA Series auto refractors for paperless operation.

EHR Integration: Compatible with Electronic Health Record (EHR) systems for streamlined documentation.

Specifications: Lightweight and portable with a durable frame, suitable for optometry offices, eyewear retail stores, and optical laboratories.

Weight: Lightweight design, exact weight not specified.

Power Supply: Includes a built-in rechargeable battery for convenience in various settings.

Additional Features

Ease of Use: Simple, fast, and accurate operation with an intuitive interface, reducing operator error.

Durability: Constructed with high-quality materials for longevity.

Applications:

Used by optometrists, ophthalmologists, and optical technicians to verify prescription lenses for accurate visual correction.Ideal for measuring a wide range of lenses in clinical and laboratory settings.
