Mortara ELI 250 ECG/EKG System

The Mortara ELI 250 is a highly reliable 12-lead resting electrocardiograph (ECG/EKG) system widely utilized in hospitals, private clinics, and clinical research facilities. Manufactured under the Burdick and Mortara brands (now part of Baxter/Hillrom), it is engineered for high-density data capture, accurate data analysis, and seamless clinical workflow.

Key Technical Specifications

• Data Acquisition: Features advanced pacemaker spike detection with a 40,000 sps/channel data capture rate and 1,000 sps/channel capture for precise signal assessment.
• Interpretation Algorithm: Integrates the globally recognized Mortara VERITAS™ resting interpretation software, providing a "silent second opinion" using age- and gender-specific adult and pediatric criteria.
• Internal Storage: Securely holds up to 60 digital ECG records internally, with some models offering an optional expansion up to 150 records.
• Paper & Print Format: Built-in thermal printer that accommodates full-size, Z-fold 8.5" x 11" or A4 paper. It supports multiple standard and Cabrera layouts (3+1, 3+3, 6-channel, and 12-channel outputs).
• Physical Profile: Highly portable unit weighing approximately 11.25 lbs (5.1 kg) with dimensions of 15.5" x 17" x 4".
